Full integrated PCB Copy service at one place
#1. IC Unlock + PCB Reverse engineering Services
#2. Fast PCB / PCBA Prototype
#3. Prototype testing & error correction
#4. Engineering files correction per testing result
#5. PCB / PCBA Re-production
Choose The Right PCB Copy Service Partner
The failure of a PCB Copy project may cuased by multiple reasons. The IC unlock unsucessful, PCB trace inaccuracy, PCB BOM doesn’t match orginal, or new components incompatiblity issue, parcitular parts sourcing difficulty & etc.. To avoide your PCB Copy project falles into the responsibility gaps between your PCB Copy partners, and lower the project failure risk for the situations just mentioned, we strongly suggest you to choose ONLY ONE partner for your PCB Copy project, instead of cooperating with mulpile partners at the same time.
Closely networking with PCB / PCBA manufacturers around Shenzhen, Fast PCB Studio is able to provide you the fully integrated PCB Copy services. The total solution from your PCB / PCBA sample given to PCB / PCBA Prototype and re-production. The major issues will mainly come from the engineering aspect, therefore, to have the engineering studio leading a re-production project will be the most effective manner to fix all possible issues.
Your re-production quality would be assured by the advanced incoming material quality control process, and strictly followed ISO Quality System.
Service Details
1. Capability
- 1-8 layer PCB mainly, board with RF components may not be able to clone in some cases
2. Service content
- After PCB reverse engineering with Fast PCB Studio, we could also provide prototype + Reverse engineered PCB prototype error fixing services
- In general, we don’t provide prototype for other vendors’ PCB reverse engineering work. Since we did not participate the processes of board reverse engineering, there may be errors that we did not detect, so there will be more difficult for us to fix the errors.
3. Pricing
- From USD600 – USD1500 / 5pcs in general, but the price could vary depending on the cost of components, and PCB technics.
- We will need PCB file + BOM to provide formal quotation, so generally, the quotation is availble after our PCB reverse engineering service done.
4. Service flow
- IC Unlock and/or PCB Reverse Engineering Services
- 50% initial payment + 50% final payment after testing and/or work completion
- Quote for Prototype and/or re-production
- 100% payment before PCBA Prototype
- Prototype complete.
- Testing & error fixing
- Modify BOM and/or PCB file per error findings
- Testing Done. Sending prototypes back to customer for approval
- Approval received
- Start re-production for batch Qty.
- 100% payment before PCBA re-production
- Re-production done.
- Goods shipping out
- Project Closed.
PCB Copy Steps
From PCB Copy to PCBA Re-production
We copy the design of the PCBA your need, and extract the machine code of IC program for the new IC duplication. We will send you 2 duplicated IC for your testing as this stage. Shipment cost of new IC samples are not included in service charge.
a. Shipping samples to FAST PCB STUDIO
b. 50% initial payment to start the project (PCB RE or IC Unlock or both)
c. PCB RE and/or IC unlock work starts after sample & initial payment receival
d. Unlock and/or RE work completion, sending proof of work (IC samples and/or PCB PDF Schematics / Gerber screenshot)
e. Final 50% payment receival
f. Submit all the engineering files
g. Close the project of IC unlock and/or PCB RE
We will quote the PCBA for you once we obtain all the engineering files for re-production. The quotation for sampling and mass production will be available at this stage.
The same PCBA samples will be built for testing & debug. We will send you the sample boards for your approval before MP.
a. Quote for Prototype & Mass production
b. 100% payment before PCBA Prototype
c. Prototype complete. Testing & Debug, BOM / PCB file correction
d. Sending prototypes back to customer for testing
e. Approval of prototypes received from customer
We will manufacture then delivery the MP of PCBA to your address.
a.100% payment receival before mass production
b.PCBA component sourcing + Assembly + Testing
c.PCBA MP ready to ship out
Why Us
Fast PCB Studio is one of the Leading PCB Copy & IC Unlock service provider in Dongguan, China. We are dedicated to provide our clients the very reliable & cost effective Full solution for Electronic Reverse Engineering & Production.
(1) Under normal circumstances, the single-layer and double-layer board take upto 3-5 working days, the 4-6 layer board takes upto 7 to 12 workding days, and the 10+ layer board takes upto 12 to 15 working days. The multilayer board depends on the complexity of the circuit board;
(2) We have strong R&D resources and strong R&D support team in Beijing and Shenzhen, and we have our own talent training tutorial from experienced PCB reverse engineered in Shenzhen, which ensures 100% accuracy of PCB copy board;
(3) “To create a win-win situation with customers” is always our principle for cooperation. Based on your specific requirements, we will provide the most reasonable quotes in very short time, and would help to evaluate the cases from your pictures or samples free of charge.
*We are capable to generate the documents in various format with additional charge. In gerneral, we use software Protel99/Se.
We not only focus on advanced technology, but also carry out quality management of the entire PCB production process, including excellent product design, high-quality materials, suitable equipment, mature production processes, skilled production personnel, and strict and meticulous inspection, storage, packaging and so on.
We have the strong networks for electronic products from reverse engineering to productions. Our partners empowered us to provide the full solutions for PCB copy, PCBdesign & Modification, prototype error fixing, IC decryption (As known as IC Unlock or IC Crack), IC procurement, high-precision board production with state of art SMT facilitise, PCB assembly testing (Including BGA X-ray testing) and turnkey services. We could also provide design for products according to customer requirements, including the re-design / modification for the development of the existing product on function improvement and technical optimization in some fields.
We support our customers the after-sell services for all the designs and the productions from us.
Disclaimer: The use of our reverse engineering technologies is strictly limited within legal purposes, e.g. reproduce PCB artworks for old or obsolete printed circuit boards where the original is no longer available, PCB & Design tutorial or research and etc. Fast PCB Studio would not be responsible for any legal disputes for any inappropriate use of our technology on commercial competition, patent duplication or other prohibited use of reverse engineering technology by local laws.
